Flat Facets from BATT™.


Retail Prices for CAST BATT™ products:

EFFECTIVE MAY 1, 2008:

BATT™ 6"______________$90.00

BATT™ 8"______________$135.00

BA5T™________________ $210.00

(I amWAS betting tin prices did not go much over $17,000/Ton this year. )

Look at this obscenity!

$24,000 a ton! When the BATTs were first made it was $6,320!!!


BATT™ DEVELOPMENT-Past, Present, Future.


Latest tips and tricks from the BATT Cave!

BATT™ BRIEFS!


PAGE BACKGROUND: BATT™ Grain Structure.

BATT™ is a Trademark used to represent a proprietary alloy, principally of tin, which contains alloying metals of low or no toxicity which harden and deoxidize the alloy and establish certain grain structures which are developed by a specific annealing and quenching process.

I do not buy cheap commercial Straits Tin for my laps. Lead content batch to batch runs < 35 Parts Per Million.(Refiner's CofC.)
BATT™ alloy laps are now used by thousands of gemcutters. .

Because they are solid castings, they may be resurfaced many times, to provide years of use!




Comparative Hardnesses of some lap alloys:

ALLOY__________Hardness, Brinell:

Pure Tin___________ 5.3

63:37 Tin/Lead solder:__14

95/5__________________14

Britannia Pewter_____22.5

Sn die cast YC135A___29

BATT™________________32.5

Commercial Rolled Zinc____43

Microstructure complexity of BATT™ Alloys:

(Why they work.)

BATT™: Fractal Dimension: 1.862

BA5T™: Fractal Dimension: 1.5247

Benoit Information Dimension Method.



BATTs CUT FLAT FACETS!

PROOF HERE!

Thanks to Tom Herbst for interferometry testing and permission to reprint!


BATT™ Users' Tips and suggestions.


Let's Talk.

How to charge a new lap.


Resurfacing Service for BATT™ Laps.



BAT5T™: FASTER/HARDER/FINER



Ordering Information:

Buy your BATT ™ laps from one of these

STOCKING DEALERS

Or:

ORDER ONLINE:


BATT™ WARRANTY AND CUSTOMER SERVICE POLICY
